SF₆ Gas — Product Family

SF₆ Valves & Couplings

for Safe, Emission-Free Gas Handling

Create secure, pressure-tight connections with industry-leading SF₆ valves and couplings from DILO. Trusted worldwide for decades, DILO connection systems are designed to support safe, reliable, and emission-free gas handling across medium-voltage switchgear, high-voltage equipment, GIS, and gas-insulated lines (GIL).

From routine maintenance to large-scale gas handling operations, DILO couplings and valves help reduce gas loss, improve workflow efficiency, and ensure dependable performance in demanding environments.

Zero emissions. Proven performance.

Explore Valves and Couplings

AT A GLANCE

Leak-Tight Connections for SF₆ Handling

DILO valves and couplings create secure connections during gas recovery, filling, evacuation, and testing.

Form pressure-tight and vacuum-tight connections
Seal before gas flow begins during connection
Close automatically before equipment is disconnected
Minimize emissions and prevent air intrusion
Maintain gas quality throughout handling processes
Withstand frequent connection and disconnection cycles
Standardize connections across DILO service equipment
Support switchgear, service-cart, analyzer, and storage applications

DILO’s Self-Sealing Coupling Principle

DILO Company pioneered an innovative self-sealing coupling system that has become the industry benchmark for safe and efficient SF₆ gas handling. Designed to minimize gas loss during connection and disconnection, this proven system helps operators maintain cleaner workflows while protecting gas quality. The connection is made by simply screwing the two coupling halves together. As the coupling is tightened, an internal sealing mechanism creates a pressure-tight and vacuum-tight connection before gas flow is opened. This staged sealing process helps prevent unintended gas release during hookup.

When the coupling is loosened and disconnected, the internal self-closing valves automatically shut before the connection is fully separated. This helps retain gas inside the hose and equipment while reducing the chance of atmospheric release. Unlike conventional fittings that may rely heavily on exposed seals or manual shutoff steps, the DILO system is engineered to make secure operation faster, more repeatable, and less dependent on user technique.

Key Advantages of the DILO Self-Sealing Principle:

+ Helps minimize SF₆ emissions during connection and disconnect

+ Reliable sealing even with frequent use

+ Pressure-tight and vacuum-tight sealing performance

+ Faster, simpler connection process for technicians

+ Helps prevent moisture or air ingress into the gas system

+ Trusted worldwide across utilities, OEMs, and service teams

Typical Applications

Medium-Voltage Switchgear
Reliable service connections for filling, evacuation, and maintenance.
High-Voltage GIS Equipment
Pressure-tight connections for demanding large-scale systems.
Gas-Insulated Lines (GIL)
Durable couplings built for specialized high-performance applications.
Service Carts & Recovery Equipment
Direct integration with DILO carts, analyzers, and handling devices.

Key Performance Advantages

DILO valves and couplings are engineered for dependable performance in demanding gas handling environments, where sealing integrity, pressure capability, and durability are critical.

Self-closing coupling system for safer, cleaner gas handling
Pressure-tight and vacuum-tight performance during both connection and disconnection
Low leak rate ≤ 1 x 10⁻⁸ mbar l/s (DN6–DN20)*
Permanent tightness even with frequent coupling and uncoupling cycles
Pressure rating up to PN 64 bar for demanding applications
Operating temperature range from -40 °C to +80 °C
Direct connection to DILO service carts without additional adapters
Available in multiple materials for indoor, outdoor, and corrosive environments
Designed to help prevent moisture ingress and preserve gas quality
Trusted for long-term use across utilities, OEMs, and service providers

* DN40 versions available upon request.

Product Range

DILO offers one of the world’s most complete portfolios of SF₆ valves, couplings, adapters, and connection accessories for gas handling operations.

Available options may include:

+ Couplings in multiple nominal sizes

+ Self-sealing valves

+ Adapters for common standards

+ Hose connection fittings

+ Special materials for outdoor use

+ High-pressure connection solutions

Explore Catalog

DILO ADVANTAGE

Why Choose DILO Valves and Couplings?

DILO connection systems are trusted globally because they combine engineering precision, long service life, and dependable emission-free performance.

When you choose DILO, you gain:

Proven industry-standard connection technology
Safer gas handling workflows
Reduced gas loss
Durable field-ready hardware
Compatibility with DILO systems worldwide
